Product Details (17)
GPS Position Accuracy
3 m (10’) CEP
Operating Temperature Range
-25 to 55°C (-13 to 131°F)
Weight
300 grams (0.7 lb)
Mounting-thread Size, Base M39
Adapter on cable is standard 1”-14 UNS (3/4” NPT optional)
Certifications and Standards
CE, IPX6 (IPX4 with optional Relative Humidity sensor), RoHS, IEC61000-4-2, IEC60945, IEC60950_1C, IEC60950_22A, EN55022, EN55024, EN14982
Range
50°
Accuracy
±1° in range of ±30°
Resolution
0.1°
Calculations
User configurable damping
Measurement Type
MEMS
Supply Voltage
9 VDC to 40 VDC
Supply Current (at 12 VDC)
<75 mA (<0.9 W)
NMEA 2000® Load Equivalency Number (LEN)
2
Available Hardware Interfaces
Serial RS232, Serial RS422, CAN
Available Protocols
NMEA 0183, NMEA 2000
Serial Data Transmission Code
ASCII
Serial Output Rate
1 Hz typical. User selectable. 10 Hz max recommended
